classic range in 34mm
Classic Georgian Range of Quality Manufactured Garden Building Doors & Windows
KDW Joinery manufactures a large range of quality wooden summerhouse doors and windows, from the timeless Georgian to the modern Full Glazed. Ideal for beautiful summerhouses, Log Cabins, Garden rooms and offices.
Geo 6 Pair
Prod Code |
GEO 6 PAIR |
Height |
1780 mm |
Width |
1092 mm |
Depth |
34 mm |
Weight |
14.3kg |
Glass Size |
302h x 402w (qty6) |
Geo 9 Single
Prod Code |
GEO 9 SINGLE |
Height |
1780 mm |
Width |
755 mm |
Depth |
34 mm |
Weight |
8.7kg |
Glass Size |
302h x 612w (qty3) |
Geo 9 Pair
Prod Code |
GEO 9 PAIR |
Height |
1780 mm |
Width |
1510 mm |
Depth |
34 mm |
Weight |
17.4kg |
Glass Size |
302h x 612w (qty6) |
Geo 6c
Prod Code |
GEO 6c |
Height |
1011 mm |
Width |
475 mm |
Depth |
34 mm |
Weight |
2.4kg |
Glass Size |
302h x 402w (qty3) |
GEO 9c
Prod Code |
GEO 9c |
Height |
1011 mm |
Width |
685 mm |
Depth |
34 mm |
Weight |
3.2kg |
Glass Size |
302h x 612w (qty3) |
geo 6c tl
Prod Code |
GEO 6c TL |
Height |
1043 mm |
Width |
505 mm |
Depth |
34 mm |
Weight |
4.1kg |
Glass Size |
302h x 402w (qty2) |
 |
238h x 402w (qty1) |
geo 9c tl
Prod Code |
GEO 9c TL |
Height |
1043 mm |
Width |
717 mm |
Depth |
34 mm |
Weight |
4.8kg |
Glass Size |
302h x 612w (qty2) |
|
238h x 612w (qty1) |
geo 8 pair
Prod Code |
GEO 8 PAIR |
Height |
1780 mm |
Width |
1092 mm |
Depth |
34 mm |
Weight |
14.5kg |
Glass Size |
302h x 402w (qty8) |
geo 12 single
Prod Code |
GEO 12 SINGLE |
Height |
1780 mm |
Width |
755 mm |
Depth |
34 mm |
Weight |
8.8kg |
Glass Size |
302h x 612w (qty4) |
geo 12 pair
Prod Code |
GEO 12 PAIR |
Height |
1780 mm |
Width |
1510 mm |
Depth |
34 mm |
Weight |
17.6kg |
Glass Size |
302h x 612w (qty8) |
geo 8c
Prod Code |
GEO 8c |
Height |
1330 mm |
Width |
475 mm |
Depth |
34 mm |
Weight |
2.6kg |
Glass Size |
302h x 402w (qty4) |
geo 12c
Prod Code |
GEO 12c |
Height |
1330 mm |
Width |
685 mm |
Depth |
34 mm |
Weight |
3.6kg |
Glass Size |
302h x 612w (qty4) |
geo 8c tl
Prod Code |
GEO 8c TL |
Height |
1362 mm |
Width |
505 mm |
Depth |
34 mm |
Weight |
5.5kg |
Glass Size |
302h x 402w (qty3) |
|
238h x 402w (qty1) |
geo 12c tl
Prod Code |
GEO 12c TL |
Height |
1362 mm |
Width |
717 mm |
Depth |
34 mm |
Weight |
6.5kg |
Glass Size |
302h x 612w (qty3) |
|
238h x 612w (qty1) |
Sales Open 9.30am to 4.30pm Mon to Fri - Tel: 01623 751100 email: kdwjoinery@resource24.net
Copyright 2015 - 2017 KDW Joinery all rights reserved
geo 10 pair
Prod Code |
GEO 10 PAIR |
Height |
1780 mm |
Width |
1092 mm |
Depth |
34 mm |
Weight |
14.5kg |
Glass Size |
302h x 402w (qty10) |
geo 15 single
Prod Code |
GEO 15 SINGLE |
Height |
1780 mm |
Width |
755 mm |
Depth |
34 mm |
Weight |
8.8kg |
Glass Size |
302h x 612w (qty5) |
geo 15 pair
Prod Code |
GEO 15 PAIR |
Height |
1780 mm |
Width |
1510 mm |
Depth |
34 mm |
Weight |
17.6kg |
Glass Size |
302h x 612w (qty10) |
geo 10c
Prod Code |
GEO 10c |
Height |
1647 mm |
Width |
475 mm |
Depth |
34 mm |
Weight |
3.4kg |
Glass Size |
302h x 402w (qty5) |
geo 15c
Prod Code |
GEO 15c |
Height |
1647 mm |
Width |
685 mm |
Depth |
34 mm |
Weight |
4.5kg |
Glass Size |
302h x 612w (qty5) |
geo 10c tl
Prod Code |
GEO 10c TL |
Height |
1679 mm |
Width |
505 mm |
Depth |
34 mm |
Weight |
6.9kg |
Glass Size |
302h x 402w (qty4) |
|
238h x 402w (qty1) |
geo 15c tl
Prod Code |
GEO 15c TL |
Height |
1679 mm |
Width |
717 mm |
Depth |
34 mm |
Weight |
8.2kg |
Glass Size |
302h x 612w (qty4) |
|
238h x 612w (qty1) |
geo 4c
Prod Code |
GEO 4c |
Height |
692 mm |
Width |
475 mm |
Depth |
34 mm |
Weight |
1.7kg |
Glass Size |
302h x 402w (qty2) |
geo 5c
Prod Code |
GEO 5c |
Height |
692 mm |
Width |
685 mm |
Depth |
34 mm |
Weight |
2.4kg |
Glass Size |
302h x 612w (qty2) |
geo 3c
Prod Code |
GEO 3c |
Height |
1011 mm |
Width |
265 mm |
Depth |
34 mm |
Weight |
1.6kg |
Glass Size |
938h x 192w (qty1) |
geo 6/6/6
Prod Code |
GEO 6/6/6 |
Height |
1011 mm |
Width |
505 mm |
Depth |
34 mm |
Weight |
7.2kg |
Glass Size |
302h x 402w (qty9) |
geo 3/9/3
Prod Code |
GEO 3/9/3 |
Height |
1011 mm |
Width |
717 mm |
Depth |
34 mm |
Weight |
6.4kg |
Glass Size |
302h x 612w (qty3) |
|
938h x 192w (qty2) |
Georgian Range
As standard our Georgian range is supplied as Dummy Sparred
